Rated Capacity: 5000W
Peak Capacity: 10000W
Rated DC Voltage: 48V
Grid Power Input
Voltage: 208/220/230/240VAC Frequency: 50Hz/60Hz(Auto Sensing) Max charging current: 80 A
Inverter Output: Voltage: 208/220/230/240VAC±5% Frequency: 50/60Hz±0.1%
Waveform: Pure Sine Wave
Solar Input: PV Max Input Power: 5500W
Max PV Input Voltage: 450 VDC Max PV Charge Current: 80 A MPPT Tracking Range: 120~430 VDC
Battery Rated Voltage: 48Vdc
Communication: RS232,RS485, USB, parallel, WIFI+bluetooth (external )
Protection: short-circuit, over-voltage, under- voltage, over discharge
PLEASE NOTE - DELIVERY AND INSTALLATION NOT INCLUDED
